Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966

Certificat
LA CHINE Yitao Air Spring Group certifications
LA CHINE Yitao Air Spring Group certifications
Je suis en ligne une discussion en ligne

Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966

Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966

Image Grand :  Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966

Détails sur le produit:
Lieu d'origine: Chine
Nom de marque: YITAO
Certification: IATF16949
Numéro de modèle: 1V8708/0V17CA-6.5
Conditions de paiement et expédition:
Quantité de commande min: 50 pièces
Prix: Negotiable in person
Détails d'emballage: CARTON
Délai de livraison: 1 ~ 30 jours
Conditions de paiement: T/T
Capacité d'approvisionnement: 5000pièces/mois

Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966

description de
Numéro OE: W01-358-8708,1T17CA-6.5,1R13-177,566263078,1010-16 P 526,1R13-250,S-21966 Numéro YITAO: 1V 8708
Taper: Ressort pneumatique de camion Condition: Tout neuf
Garantie: 12 mois Délai d'expédition typique: 3-10 jours
Configuration d'étanchéité: Plaque de recouvrement à sertir + plaque d'étanchéité vulcanisée Matériel: Caoutchouc naturel
Matériau des pistons: Oui Emballage: Emballage neutre ou emballage personnalisé
Mettre en évidence:

Hendrickson trailer air spring

,

Contitech OE replacement air spring

,

trailer air suspension rubber spring

Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966

Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966

Compatibility
  • Automann 1DK25E-8708
  • Firestone No. W01-358-8708
  • Firestone Style 1T17CA-6.5
  • FleetPride AS8708
  • Goodyear 1R13-177
  • Goodyear Flex No. 566263078
  • Primeride AS PR10B16 8708
  • Road Choice AS8708
  • Triangle AS-8526
  • TRP AS87080
Product Overview

Manufactured to specifications matching Andrew H14-1358106 and Dunlop FR D13B26, this air spring fully replaces the original equipment and provides a comfortable and stable ride.

Cross References
Brand Reference Numbers Numbering Discrepancy
Firestone W01-358-8708 W013588708 / W01-358-8708 / W01 358 8708
Firestone 1T17CA-6.5 1T17CA6.5 / 1T17CA-6.5 / 1T17CA 6.5
Goodyear 1R13-177 1R13177 / 1R13-177 / 1R13 177
Goodyear 566263078 :566263078
Contitech 1010-16 P 526 101016P526 / 1010-16 P 526 / 1010 16 P 526
Navistar 1R13-250 1R13250 / 1R13-250 / 1R13 250
Hendrickson Trailer S-21966 S21966 / S-21966 / S 21966
Technical Specifications
Specifications Parameters
Outer diameter φ270
Weight 7.826 kg
Package Dimensions 27*27.5*30cm
Natural height 549mm
Maximum height 529mm
Minimum height 173mm
Extended Height /
Compressed Height /
Top Plate Width 262mm
Piston Width 234mm
Product Drawings & Images
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 0 Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 1 Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 2

Images shown are for reference only. Actual product may vary slightly.

Factory Showcase
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 3
Quality Control Inspection
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 4
Manufacturing Equipment
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 5
R&D Center
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 6
Assembly and Forming
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 7
Vulcanization Shop
Full Trailer Air Suspension Rubber Air Spring OE Replacement Contitech 1010-16 P526, Hendrickson Trailer S-21966 8
Delivery Information
  • Delivery Time: Orders are typically shipped after payment is received. Depending on order size, shipment will be completed within 1-30 business days
  • Packing Method: Brown carton packing; we can also pack according to your requirements
  • Shipping Marks: Generally display weight and size. We can also make shipping marks according to your requirements
  • Transportation Methods: Sea transportation, air transportation, express delivery, railway transportation and various combined transportation methods
  • International Transport Notes: Due to international transportation requirements, we pack according to strict standards to avoid damage. If logistics information is stagnant during transportation, please wait patiently. Contact us with any questions
Frequently Asked Questions

IS THE SAMPLE AVAILABLE?
Yes, we typically send samples via TNT, DHL, FEDEX or UPS. Delivery takes approximately 3 days. Customers are responsible for sample costs and airmail freight. Sample costs will be refunded after order placement.

WHAT IS YOUR WARRANTY TERM?
Full container load orders receive 1% free spare parts. Export products carry a 12-month warranty from the shipment date. For product failures within the warranty period, customers are responsible for replacement part costs.

CAN I USE MY OWN LOGO AND DESIGN ON PRODUCTS?
Yes, OEM services are welcomed.

I CANNOT FIND THE ITEMS I WANT FROM YOUR WEBSITE, CAN YOU OFFER THE PRODUCTS I NEED?
Yes. We provide product sourcing services for our customers. Please provide detailed information about the items you require.
